| Pass Channel Wavelength |
1530-1570nm |
| Reflective Channel Wavelength |
915+/-10nm |
| Signal/Pump Insertion Loss |
<=1.3dB (Single Stage), <=1.4dB (Dual Stage)
<=1.6dB (H Stage) /<=1.0dB |
| Signal Isolation |
>=28dB (Single Stage), >=45dB (Dual Stage)
>=25dB (H Stage) |
| Signal Tap Ratio |
1%, 2%, 5%, 10%, 20%, 30%, 40%, 50% |
| Signal/Pump Wavelength Isolation |
>=25dB/>=12dB |
| Return Loss |
>=45dB |
| Extinction Ratio |
>=18dB |
| Fiber Type (Signal) |
PM1550 Fiber or 10/125um PMDC Fiber
12/130um PMDC Fiber or 20/130um PMDC Fiber
25/250um PMDC Fiber or 25/300um PMDC Fiber |
| Fiber Type (Common/Pump/Tap) |
Common: Same Fiber or PM850 Fiber
Pump: Same Fiber, PM850 Fiber, HI780 Fiber or PM980 Fiber
Tap: Same Fiber or Corr. SM Fiber |
| Max. Average Power |
300mW, 500mW, 1W, 2W, 3W, 5W, 10W, 15W, 20W |
| Max. Peak Power for Pulse |
100W, 1kW, 2kW, 3kW, 5kW, 10kW, 15kW, 20kW |
| Operating Temperature |
0~50degreeC |
