| Center Wavelength |
1570~1600nm |
| Reflectivity |
0.5~99.9% |
| FWHM |
1~20nm |
| Side Mode Suppression Ratio (SMSR) |
A: >=8dB; B: >=10dB; C: >=15dB;
D: >=20dB; E: >=25dB |
| Extinction Ratio (for PM Fiber Type) |
>=18dB |
| SM Fiber Type |
SMF-28 Fiber, 8/125um NA=0.12(M), 6/125um NA=0.18(M1),
10/130um NA=0.075(O), 12/130um NA=0.2(T), 15/130um NA=0.075(W), |
| SM Fiber Type |
20/130um NA=0.075(Q), 25/250um NA=0.065(R), 25/300um NA=0.09(G),
25/400um NA=0.065(R1), 30/250um NA=0.06(R6), 30/400um NA=0.06(R3),
or specified by customer |
| PM Fiber Type |
PM1550 Fiber, 8/125um NA=0.12(M), 6/125um NA=0.18(M1),
10/130um NA=0.075(O), 12/130um NA=0.2(T), 15/130um NA=0.075(W), |
| PM Fiber Type |
20/130um NA=0.075(Q), 25/250um NA=0.065(R), 25/300um NA=0.09(G),
25/400um NA=0.065(R1), 30/250um NA=0.06(R6), 30/400um NA=0.06(R3),
or specified by customer |
| Max. Signal Optical Power (CW) |
1W, 5W, 10W, 30W, 50W, 100W, 300W, 500W,
1000W, 2000W, 3000W |
| Max. Cladding Optical Power (CW) |
1W, 5W, 10W, 30W, 50W, 100W, 300W, 500W,
1000W, 2000W, 3000W |
| Operating Temperature |
0~50degreeC |
