| Center Wavelength |
1050~1074nm |
| Reflectivity |
0.5~99.9% |
| FWHM |
0.1~3.0nm |
| Side Mode Suppression Ratio (SMSR) |
A: >=8dB; B: >=10dB; C: >=15dB;
D: >=20dB; E: >=25dB |
| Extinction Ratio (for PM Fiber Type) |
>=18dB |
| SM Fiber Type |
HI1060 Fiber, 6/125um NA=0.14(N), 5/130um NA=0.12(N1),
10/125um NA=0.075(O), 15/130um NA=0.075(W), 20/130um NA=0.075(Q), |
| SM Fiber Type |
25/250um NA=0.065(R), 25/400um NA=0.065(R1), 30/250um NA=0.06(R6),
30/400um NA=0.06(R3) or specified by customer |
| PM Fiber Type |
PM980 Fiber, PM1060L Fiber (E), 6/125um NA=0.14(N),
5/130um NA=0.12(N1), 10/125um NA=0.075(O), 15/130um NA=0.075(W), |
| PM Fiber Type |
20/130um NA=0.075(Q), 25/250um NA=0.065(R), 25/400um NA=0.065(R1),
30/250um NA=0.06(R6), 30/400um NA=0.06(R3) or specified by customer |
| Max. Signal Optical Power (CW) |
1W, 5W, 10W, 30W, 50W, 100W, 300W, 500W,
1000W, 2000W, 3000W |
| Max. Cladding Optical Power (CW) |
1W, 5W, 10W, 30W, 50W, 100W, 300W, 500W,
1000W, 2000W, 3000W |
| Operating Temperature |
0~50degreeC |
